WEG CFW-09 - Page 197

198
CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
This feature prevents the motor from operating permanently at speeds
where the mechanical system enters into resonance, causing high
vibrationor noise levels.
The passage through the skip speed band (2 x P306) is made at the
programmed acceleration/deceleration rates.
This function does not operate properly when two skip speeds are
overlapped.
Range
[Factory Setting]
Parameter
Unit
Description / Notes
P308
(1)
1 to 30
SerialAddress
[ 1 ]
-
Sets the address of the inverter for the serial communication. Refer to
item 8.13.
Defines the Fieldbus standard to be used (Profibus DP/DP-V1,
DeviceNet, EtherNet/IP or DeviceNet Drive Profile) and the number of
variables to be exchanged with the master. Refer to item 8.12.7.
P309
(1)
0 to 10
Fieldbus
[ 0 ]
-
It’s onlyapplicableif an optionalFieldbus communication kit were used.
Table 6.49
- Fieldbus options
P309
Fieldbus Options
0
Inactive
1
Profibus DP/DP
-
V1 2 I/O
2
Profibus DP/DP
-
V1 4 I/O
3
Profibus DP/DP
-
V1 6 I/O
4
DeviceNet 2 I/O
5
DeviceNet 4 I/O
6
DeviceNet 6 I/O
7
EtherNet/IP 2 I/O
8
EtherNet/IP 4 I/O
9
EtherNet/IP 6 I/O
10
DeviceNet Drive P
rofile
NOTE!
If the PLC1 or PLC2 boards are used, the parameter P309
must be programmed as inactive.
P310
(1)
0 or 1
STOP Detection in a
[ 0 ]
Profibus Network
-
This parameter allows programming the bit #6 of the Fieldbus control
word (refer to item 8.12.7.2 - Variable Written in the Inverter).
Table 6.50 -
STOP detection in a Profibus network
P310
Function
B
it
#
6
CFW
-
09 Action
0
Off
No function
-
If bit6 = 0
Executes a General
Disable command,
regardless of the value of
the remaining bits of the
control word.
1
On
If bit6 = 1
Executes the commands
that were programmed at
the remaining bi
ts of the
control word.
