CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
This parameter is applicable only if an optional DeviceNet Drive Profile
communication kit were used.
It allows programming the I/O instances used by the DeviceNet Drive
Profile interface. These instances define the contents and the number
of I/O words exchanged with the network master.
The modification of this parameter will become valid only after cycling
the power of the inverter.
Inorder togetmoreinformationontheparameterizationandtheoperation
of the DeviceNetDrive Profile interface, referto the CFW-09frequency
inverter DeviceNet Drive ProfileCommunication Manual.
These parameters are applicable only if an optional DeviceNet Drive
Profile communication kit were used.
The parameters P336 to P340 permit programming the content of the
input words 3 to 7 (input: the inverter sends to the master). Using these
parameters it is possible to program the number of another parameter
whose content must be made available at the network master input
If for instance one wants to read from the CFW-09 inverter the motor
current in Amps, one must program the value 3 in one of these
parameters, because the parameter P003 is the one that contains this
information. It is worthwhile to remind that the value read from any
parameter is represented with a 16 bit word with sign, in two’s
complement. Evenif the parameter has decimalresolution, the value is
transmitted without the indication of the decimal point. E.g., if the
parameter P003 has the value 4.7A, the value supplied via thenetwork
These parameters are used only if the number of input/output words
programmed in P346 were greater than 2, andif the I/O instances 102/
103 were programmed in P335.
Inorder togetmoreinformationontheparameterizationandtheoperation
of the DeviceNet DriveProfile interface, refer to the CFW-09frequency
inverter DeviceNet Drive ProfileCommunication Manual.
