WEG CFW-09 - Page 347

348
CHAPTER9 -
TECHNICAL
SPECIFICA
TIONS
Conduit for
power
cable
(3x) 35

Air Flow
outlet
Air Flow
inlet
Air Flow
outlet
Air Flow inlet
219(8.62)
34
(1.34)
34
(1.34)
62.5(2.46)
111.5(4.39)
160.5 (6.32)
223(8.78)
147(5.79)
197.5 (7.78)
274(10.78)
390(15.35)
370(14.57)
375(14.76)
223(8.78)
84.5(3.33)
150(5.91)
36.5(1.44)
10 (0.39)
372(14.65)
150(5.91)
225(8.86)
400(15.75)
37.5(1.48)
14 (0.55)
7.2(0.28)
24.6(0.97)
16
(0.63)
13 (0.51)
5 (0.20)
7.2(0.28)
8.6(0.34)
SIZE 3
Figure 9.4
- Size 3 - dimensions in mm (inch)
