WEG CFW-09 - Page 349

350
CHAPTER9 -
TECHNICAL
SPECIFICA
TIONS
SIZE 5
Conduit for
power
cable
(3x) 50.0

Air Flow
outlet
Air Flow
inlet
Air Flow
outlet
Air Flow inlet
34
(1.34)
34
(1.34)
95.5(3.76)
167.5 (6.59)
154.5 (6.08)
239.5 (9.43)
203.5 (8.30)
274(11.18)
9.2(0.36)
20
(0.79)
29.6(1.17)
15 (0.59)
10 (0.39)
14.6(0.57)
9.2(0.36)
67.5(2.66)
200(7.87)
525(20.67)
525(20.67)
15 (0.59)
550(21.65)
335(13.19)
84.5(3.33)
337(13.27)
200(7.87)
68.5(2.70)
555(21.85)
527(20.75)
14 (0.55)
Figure 9.6
- Size 5 - dimensions in mm (inch)
