WEG CFW-09 - Page 74

75
CHAPTER 3 - INSTALLATIONANDCONNECTION
a) EPCOS B84143A8R105 Filter
Figure 3.20 a) and b)
- EMC filters for CFW-09 inverter series [dimensions in mm]
b) EPCOS B84143A16R105 Filter
PE M4 x 11
133.7
8
Terminals 4 mm²
L1
L2
L3
Marking
LINE
LOAD
155
165
L1'
L2'
L3'
50
38
51.4
4.5
6.3
1.5
PE M5 x 15
L1
L2
L3
L1'
L2'
L3'
LINE
LOAD
Marking
38
4.5
1.5
70
199.5
Terminals 4 mm²
221
231
9
60
46.4
