CHAPTER 3 - INSTALLATIONANDCONNECTION
c) EPCOS B84143A25R105 Filter
Figure 3.20 c) and d)
- EMC filters for CFW-09 inverter series [dimensions in mm]
d) EPCOS B84143A36R105 and B84143A50R105 Filter
PE M5 x 15
L1
L2
L3
L1'
L2'
L3'
LINE
LOAD
Marking
38
4.5
1.5
83
199.5
PE M6 x 14
221
231
9
60
46.4
PE M6 x 14
L1
L2
L3
L1'
L2'
L3'
LINE
LOAD
Marking
35
4.5
1.5
90
200
Terminals 10 mm²
255
265
8
70
58
