WEG CFW-09 - Page 77

78
CHAPTER 3 - INSTALLATIONANDCONNECTION
g) EPCOS B84143A120R105 Filter
h) EPCOS B84143G150R110 Filter
Figure 3.20 g) and h)
- EMC filters for CFW-09 inverter series [dimensions in mm]
Terminals 35 mm²
PE M10 x 34
L1
L2
L3
L1'
L2'
L3'
LINE
LOAD
Marking
1.5
240
290
255
25
150
6.5
65
63
90
13
46
100
PE M10 x 35
L1
L2
L3
LINE
LOAD
Marking
6.5
0.5
350
L3'
200
100
40
78
Terminal
blocks
50mm
2
380
365±0.5
86
65±0.3
Litz wire markings
Wire end ferrule
500±10
Litz wire
L2'
L1'
PE
90
