CHAPTER 3 - INSTALLATIONANDCONNECTION
q) Schaffner FN3258-7-45, FN3258-16-45, FN3258-30-47, FN3258-55-52, FN3258-100-35 and FN3258-130-35 filters
Type/35-Terminalblock forflexibleand
rigid cable of 50 mm
2
or AWG1/0.
Max.Torque: 8 Nm
Type/45 - Terminal blockfor6 mm
2
solid
cable,4 mm
2
flexiblecableAWG 12.
Type/47 -Terminal blockfor 16 mm
2
solidwires,10mm
2
flexiblewires
AWG8.
Type/52 -Dimesions in mm(inch)
Terminal block for 25 mm
2
solid
wires,16 mm
2
flexible wiresAWG6.
FRONTVIEW
MECHANICALDATASIDE VIEW
Connector
Rated Current
Top
Figure 3.20 q)
- EMC filters for CFW-09 inverter series [dimensions in mm (in)]
