CHAPTER 3 - INSTALLATIONANDCONNECTION
r) Schaffner FN3359-150-28, FN3359-250-28, FN3359-400-99, FN3359-600-99 and FN3359-1000-99 filters
Types 150 A to 250 A
Types 400 A to 1000 A
Type/28
M10 bolt
Top
Bus bar connection(Type/99)
Series FN 2259
These filters are supplied with M12
bolts for the grounding connection.
Top
Connector
RATED CURRENT
Figure 3.20 r)
- EMC filters for CFW-09 inverter series [dimensions in mm]
NOTE!
Thedeclaration of conformityCEisavailable onthe websitewww.weg.net
or on the CD, which comes with the products.
