CHAPTER 4 - KEYPAD (HMI) OPERATION
Table 4.2
- Incompatibility between parameters - E24
(4)
To allow thereprogramming of anyparameter valueit is required tochange
parameter P000 to thepassword value. The factorydefault password value is
5.Otherwise you canonlyread the parametervalues andnot reprogram them.
For more detail
refer to
P000 description in chapter 6.
1)
Two or more parameters between P264 or P265 or P266 or P267 or P268 or P269 and P270 equal to 1 (LOC/REM).
2)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 6 (Ramp 2).
3)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 9 (Speed/Torque).
4)
P265 equal to 8 and P266 different than 8 or vice versa (FWD Run / REV Run).
5)
P221 or P222 equal to 8 (Multispeed) and P266

7 and P267

7 and P268

7.
6)
[P221 = 7 or P222 = 7] and [(P265

5 and P267

5) or (P266

5 and P268

5)].
(with reference = E.P. and without DIx = increase E.P. or without DIx = decrease E.P.).
7)
P264 and P266 equal to 8 (Reverse Run).
8)
[P221

7 and P222

7] and [(P265 = 5 or P267 = 5 or P266 = 5 or P268 = 5)].
(without reference = E.P. and with DIx = increase E.P. or with DIx = decrease E.P.).
9)
P265 or P267 or P269 equal to 14 and P266 and P268 and P270 different than 14 (with DIx = Start and DIx

Stop).
10)
P266 or P268 or P270 equal to 14 and P265 and P267 and P269 different than 14 (with DIx

Start and DIx = Stop).
11)
P220 > 1 and P224 = P227 = 1 without any DIx set for Start/Stop or DIx = Fast Stop or General Enable.
12)
P220 = 0 and P224 = 1 and without DIx = Start/Stop or Fast Stop and without DIx = General Enable.
13)
P220 = 1 and P227 = 1 and without DIx = Start/Stop or Fast Stop and without DIx = General Enable.
14)
DIx = START and DIx = STOP, but P224

1 and P227

1.
15)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 15 (MAN/AUT).
16)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 17 (Disables
Flying Start).
17)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 18 (DC Voltage Regulator).
18)
Two or more parameters between
P265 or P266 or P267 or P268 or P269 and P270
equal to 19 (Parameter Setting Disable)
.
19)
Two or more parameters between P265, P266, P267, P268 and P269 equal to 20 (Load user via DIx).
20)
P296 = 8 and P295 = 4, 6, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, or 49 (P295 incompatible with inverter model – To avoid damages
of the internal inverter components).
21)
P296 = 5, 6, 7 or 8 and P297 = 3 (P297 incompatible with inverter model).
22)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 21 (Timer RL2).
23)
Two or more parameters between P265 or P266 or P267 or P268 or P269 and P270 equal to 22 (Timer RL3).
24)
P265 or P266 or P267 or P268 or P269 or P270 = 21 and P279

28.
25)
P265 or P266 or P267 or P268 or P269 or P270 = 22 and P280

28.
26)
P279 = 28 and P265 or P266 or P267 or P268 or P269 or P270

21.
27)
P280 = 28 and P265 or P266 or P267 or P268 or P269 or P270

22.
28)
P202

2 and P237 = 1 or P241 = 1 or P265 to P270 = JOG+ or P265 to P270 = JOG-.
29)
P203 = 1 and P211 = 1 and [P224 = 0 or P227 = 0]
30)
P220 = 0 and P224 = 1 and P227 = 0 or P227 = 1 and P263 = 0
31)
P220 = 1 and P224 = 0 or P224 = 1 and P227 = 1 and P263 = 0
32)
P220 = 2 and P224 = 0 or P224 = 1and P227 = 0 or P227 = 1 and P263 = 0
E24 - Incompatibility between parameters
