CHAPTER 5 - START-UP
Selected Inverter RatedVoltage:
1 =
380 V
Exit the programming mode
Motor Rated Voltage:
0 to 690 V
Enter the programmingmode
Programmed Motor Rated Voltage:
380 V
Exit the programming mode
Motor Rated Current Range:
(0.0 to 1.30) x P295
(1)
Enter the programmingmode
Press the key to save the
selected option and exit the
programming mode
Press the key to go to the next
parameter
Press the key to enter the
programming mode
Use the and keys to set
the correct motor rated voltagevalue
Press the key to save the
programmed value and exit the
programming mode
Press the key to go to the next
parameter
