CHAPTER 5 - START-UP
ACTION
LED DISPLAY
DESCRIPTION
LCD DISPLAY
M
o
t
o
r
Rated
r
pm
P4
0
2
= 1
7
5
0
r
p
m
Use the and keys to set
the correct motor rated current value
Press the key to save the
programmed value and exit the
programming mode
Press the key to go to the next
parameter
Press the key to enter the
programming mode
Use the and keys to set the
correct motor rated frequencyvalue
Press the key to save the
programmed value and exit the
programming mode
Press the key to go to the next
parameter
Press the key to enter the
programming mode
Programmed Motor Rated Current:
7.9 A
Exit the programming mode
Motor Rated Frequency Range:
0 to 300 Hz
Enter the programmingmode
Programmed Motor Rated Frequency:
60 Hz
Exit the programming mode
Motor Rated rpm Range:
0 to 18000 rpm
Enter the programmingmode
