Maintenance
9403−3/A1
Winterthur Gas & Diesel Ltd.
5/ 11
Table 4: Tool 94180A − Pre-tensioning jack (Tie Rod − M80x6)
1 Piston 6 Back-up ring
2 Cylinder 7 O-ring
3 Vent screw 8 Back-up ring
4 Adapter 9 O-ring
5 Connection piece 10 Eyelet
94180A−KJ K
it with back-up and O-rings
for double pre-tensioning J
ack
3
WCH03123
6
7
9
8
5
4
1
2
10
Fig. 4
94180A−KJ
Hydraulic Pre-tensioning Jacks: Storage, Servicing and Maintenance
2018−02
