PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
54
445-0089-01-01
■ View / Change Battery Details:
The screens associated with these menu items display information about
the way the inverter•charger will charge the battery.
Battery Temp Coefficient
This is the relationship between temperature and voltage levels on the
battery. The correct value depends on battery type. For the correct
value, consult the battery manufacturer.
Bulk Charge Mode Settings:
Z
ZZ
Z Max Voltage
This is the maximum available charging voltage for the Bulk
charging stage.
Z
ZZ
Z
Max Current (%C)
The maximum available charging current (in A) as a percentage
of battery capacity (in Ah) for the Bulk charging stage.
Z
ZZ
Z
Exit Voltage
When the battery voltage goes above this value for the Exit
Timeout specified, the unit goes into Absorption charging stage.
Z
ZZ
Z
Exit Timeout
When the battery voltage goes above the Exit Voltage for this
time period, the unit goes into the Absorption charging stage.
Absorption Mode Settings:
Z
ZZ
Z Max Voltage
This is the maximum charging voltage for the Absorption
charging stage. Typically, the battery will be at this voltage for the
duration of this stage.
Z
ZZ
Z
Max Current (%C)
The maximum available charging current (in A) as a percentage
of battery capacity (in Ah) for the Absorption charging stage.
Z
ZZ
Z
Max Time
This is the maximum amount of time that the unit will stay in the
Absorption stage in minutes.
Z
ZZ
Z
Exit Current (%C)
When battery current goes below this value (A as % of battery
capacity in Ah) for the Exit Timeout, the unit goes into the next
charging stage.
Z
ZZ
Z
Exit Timeout
When the battery current goes below the Exit Current for this
time period in minutes, the unit goes into the next charging stage.
