SECTION 4 CONFIGURATION
445-0089-01-01
55
Overcharge Mode Settings:
Z
ZZ
Z Max Voltage
This is the maximum charging voltage for the Overcharge
charging stage. Typically the battery will be at this voltage for the
duration of this stage.
Z
ZZ
Z
Max Current (%C)
The maximum available charging current (in A) as a percentage
of battery capacity (in Ah) for the Overcharge charging stage.
Z
ZZ
Z
Max Time
The amount of time in minutes that the Overcharge stage will run.
Float Mode Settings:
Z
ZZ
Z Max Voltage
This is the maximum available charging voltage for the Float
charging stage. Typically the battery will be at this voltage for the
duration of this stage.
Z
ZZ
Z
Max Current (%C)
The maximum available charging current (in A) as a percentage
of battery capacity (in Ah) for the Float charging stage.
Z
ZZ
Z
Max Time
This is the maximum amount of time that the charger will be in
Float stage in hours.
Z
ZZ
Z
Exit Voltage
When the battery voltage goes below this value for the Exit
Timeout specified, the unit goes into Bulk charging mode.
Z
ZZ
Z
Exit Timeout
When the battery voltage goes below the Exit Voltage for this
time period, the unit goes into the Bulk charging stage.
Equalize Mode Settings:
Z
ZZ
Z Max Voltage
This is the maximum available charging voltage for the Equalize
charging stage.
Z
ZZ
Z
Max Current (%C)
This is the maximum available charging current (in A) as % of
battery capacity in (Ah) for the Equalize charging stage.
Z
ZZ
Z
Max Time
This is the maximum amount of time, in minutes, that the unit
will stay in Equalize stage.
