4-5 Data Move Instructions
Mnemonic
Function
Chapter
CMP
Data compare
4-5-1
ZCP
Data zone compare
4-5-2
MOV
Move
4-5-3
BMOV
Data block move
4-5-4
PMOV
Data block move (with faster speed)
4-5-5
FMOV
Fill move
4-5-6
EMOV
Float number move
4-5-7
FWRT
FlashROM written
4-5-8
MSET
Zone set
4-5-9
ZRST
Zone reset
4-5-10
SWAP
The high and low byte of the
destinated devices are exchanged
4-5-11
XCH
Exchange two data
4-5-12
4-5-1 Data Compare [CMP, DCMP, QCMP]
1) Summary
Compare the two data, output the result.
Data Compare [CMP,DCMP,QCMP]
16 bits
CMP
32 bits
DCMP
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable Models
XD, XL
Hardware
requirement
-
Software
requirement
-
64 bits
QCMP
Execution
condition
Normal ON/OFF/falling or
rising pulse edge
Suitable Models
XDH, XLH
Hardware
requirement
Version V3.7.1 or later
Software
requirement
Version V3.7.4a or
later
2) Operands
Operands
Function
Data Type
S1
Specify the data (to be compared) or soft
component’s address code
16/32/64 bits,BIN
S
Specify the comparand’s value or soft
component’s address code
16/32/64 bits,BIN
D
Specify the compare result’s address code
bit
3) Suitable soft component
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S1
S2
