Xinje XDH Series User Manual

204
5-5 HSC ports assignment
1)XD series PLC HSC channels list:
PLC model
HSC channel
Increasing
mode
AB phase mode
XD1
16/32
0
0
XD2/XD3
16/24/32/42/48/60
3
3
XD5
16/24/32/42/48/60
3
3
24T4/32T4/48T4/60T4
4
4
24D2T2
2
2
48D4T4
8
8
48T6/60T6
6
6
60T10
10
10
XDM
24T4/32T4/48T4/60T4
4
4
60T10
10
10
XDC
24/32/48/60
4
4
XD5E
24/30/48/60
3
3
30T4
4
4
60T4
4
4
60T6
6
6
60T10
10
10
XDME
30T4/60T4
4
4
60T10
10
10
XDH
30A16(L)/60T4/60A32
4
4
XL1
16
0
0
XL3
16/32
3
3
XL5
16/32
3
3
32T4
4
4
XL5E
16/32
3
3
32T4
4
4
64T6
6
6
64T110
10
10
XLME
32T4
4
4
64T10
10
10
XLH
24A16(L)
4
4
Note: The hardware versions of XL5E-64T6 starting with H4 support six-channel high-speed
counting, while versions starting with H3 only support four-channel high-speed counting.
2)Each letter’s Meaning:
U
A
B
Z
Pulse input
A phase input
B phase input
Z phase pulse catching
Note: Z phase signal counting function is in developping.
Under normal conditions, input frequency of X0 and X1 can reach 80KHz and 50KHz
respectively in single-phase and AB phase modes. The other terminals have maximum
frequency of 10KHz and 5KHz respectively in single-phase and AB phase modes.
