ZRST M500 M559
D0 D100
D1· D2·
D1· D2·
X0
ZRST
are specified as the same type of soft units, and
When > , only reset the specified soft unit, and set SM409, SD409 = 2.
RST can reset one soft component. The operand can be Y, M, HM, S, HS, T, HT, C, HC, TD,
HTD, CD, HCD, D, HD
FMOV can move 0 to these soft components: DX, DY, DM, DS, T(TD), HT(HTD), C(CD),
HC(HCD), D, HD.
4-5-11 Swap the high and low byte [SWAP]
1) Summary
Swap the high and low byte of specified register
High and low byte swap [SWAP]
16 bits
SWAP
32 bits
-
Execution
condition
Falling or rising pulse edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
The address of the soft element
16 bits; BIN
D2·
Reset M500~M559
Reset D0~D100
Description
D2·
D
D
D2·
D
Other Reset Instruction
