Xinje XDH Series User Manual

402
SD453
Explanation
Reason
6
Reading file
There are tasks reading files
7
Writing file
There are tasks writing files
8
Read/write error
Unplug SD card while reading and writing
9
Insufficient SD card space
Insufficient SD card space
10
Reserve
11
FAT32 error
SD card is not inserted properly, or the SD card
is not formatted as FAT32
12
Reserve
13
Reserve
14
SD card cannot be initialized
SD card is not inserted properly
15
Reserve
16
Reserve
17
Reserve
18
Reserve
19
SD card cannot be detected
SD card not inserted
20
Error in reading and writing
parameters
Check index，row，line，wordcnt
21
The read/write data does not
conform to the format
definition
Miss data type definition
22
Wrong data type of file
Appear type definitions other than
W,DW,Sn,Fx.y
23
The data type of the file is
not defined
Floating point and character data do not meet
the definition
24
Illegal file name
Index>999
25
Illegal column index
column index is greater than the number of file
columns
26
Illegal row index
Row index is less than 1
27
Illegal read and write words
The number of words read and write is less than
1
28
Illegal read and write words
Word number cannot read data completely
29
The number of characters in
the file data line exceeds the
limit
Data line characters exceed 512 characters
30
Other errors
10-5-5 Instructions for format conversion tool
1) Microsoft Office 2010 excel gadget
When making the existing data into CSV format and saving it to SD card, please use the
format conversion gadget.
Use steps:
(1) Decompress 【format conversion.rar】 to any directory.
(2) Open excel and execute file - > options to open the excel Options dialog box.
(3) As shown in the following figure, open the add in dialog box;
