 If multiple bits in the source address is 1, the high bit side is ignored, and if the source
address is 0, the instruction will not be executed.
 When the driver input is OFF, the instruction is not executed and the coding output is
unchanged.
 n = 4, the encoded object has 2
4
=16 bits, that is, bit15 ~ bit0 in D0. The encoding result is
stored in the lower 4 bits in D1, that is, bit3 ~ bit0.
 The lowest bit of 1 in D0 is bit5, ignoring all high bits 1, and encoding bit5 with bit3-bit0 as
5, bit2 and bit0 as 1.
4-8-16 Binary to Gray code [GRY]
1) Summary
Transform the binary data to gray code.
Binary to gray [GRY,DGRY]
16 bits
GRY
32 bits
DGRY
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
Soft element address need coding
16bits/32bits,BIN
D
Soft element address to save coding result
16bits/32bits,BIN
3) Suitable soft components
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
FD
TD
CD
DX
DY
DM
DS
K/H
ID
QD
X
Y
M
S
T
C
Dn.m
S
●
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
D10GRY D100
X0
S· D·
Description
Source (BIN) → target (GRY)
