Xinje XDH Series User Manual

178
ESQR D10 D20
X0
S· D·
 A square root is performed on the floating point value S; the result is stored in D.
 If a constant K or H used as source data, the value is converted to floating point before the
operation.
ESQR K1024 D110
X1
 When the result is zero, zero flag activates.
 Only when the source data is positive will the operation be effective. If S is negative then an
error occurs and error flag SM409 is set ON, SD409=7, the instruction can’t be executed.
 The operand value must be floating numbers, otherwise the result will be error.
4-9-8 Sine[SIN]
1) Summary
Floating Sine[SIN]
16 bits
-
32 bits
SIN
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
The soft element address need to do sine
32 bits, BIN
D
The result address
32 bits, BIN
3) Suitable soft components
Operands
Word soft elements
Bit soft elements
System
Consta
nt
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.m
S
●
●
●
●
●
●
●
D
●
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
(D11,D10) → (D21,D20)
Binary FloatingBinary Floating
(K1024) → (D111, D110)
Binary converts to FloatingBinary Floating
Description
