Xinje XDH Series User Manual

132
M0
M1
M2
M3
M17
CML DX0 DM0
M8000
X0
X1
X2
X3
X17
 The sequential control instruction in the left could be denoted by the following CML
instruction.
4-6-9 Negative [NEG, DNEG]
1) Summary
Get the negative data
Negative [NEG,DNEG]
16 bits
NEG
32 bits
DNEG
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
D
The source data address
16 bits/ 32 bits, BIN
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
D
●
●
●
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM;S includes S,HS;T
includes T,HT;C includes C, HC.
NEG D10 (D10) +1 (D10)
M0
D·
 Converse each bit of source data (1→0, 0→1), then plus one and store the result in the source
Description
