Xinje XDH Series User Manual

141
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS;
T includes T, HT; C includes C, HC.
 Move n2 words left for the object which contains n1 words.
 When X0 changes from OFF to ON, the instruction will move n2 words for the object.
4-7-7 Word shift right [WSFR]
1)Summary
Word shift right
Word shift right [WSFR]
16 bits
WSFR
32 bits
-
Execution
condition
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2)Operands
Operands
Function
Data Type
S
Source soft element head address
16 bits, BIN
D
Target soft element head address
16 bits, BIN
n1
Source data quantity(no more than 512)
16 bits, BIN
n2
Shift right times(no more than 512)
16 bits, BIN
3)Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S
●
●
●
●
D
●
●
●
●
n1
●
●
●
●
●
●
●
●
●
n2
●
●
●
●
●
●
●
●
●
Description
①
D 3~D 0
→
D13~D10
②
D13~D10
→
D17~D14
③
D17~D14
→
D21~D18
④
D21~D18
→
D25~D22
⑤
D25~D22
→
overflow
