Xinje XDH Series User Manual

140
 Move n2 bits right for the object which contains n1 bits.
 When X0 changes from OFF to ON, the instruction will move n2 bits for the object.
 For example, if n2 is 1, the object will move 1 bit right when the instruction executes once.
4-7-6 Word shift left [WSFL]
1) Summary
Word shift left
Word shift left [ [WSFL]
16 bits
WSFL
32 bits
-
Execution
condition
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
S
Source soft element head address
16 bits, BIN
D
Target soft element head address
16 bits, BIN
n1
Source data quantity(no more than 512)
16 bits, BIN
n2
Word shift left times (no more than 512)
16 bits, BIN
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Modul
e
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S
●
●
●
●
D
●
●
●
●
n1
●
●
●
●
●
●
●
●
●
n2
●
●
●
●
●
●
●
●
●
Description
①
X3~X 0
→
M15~M12
②
M15~M12
→
M11~M8
③
M11~M 8
→
M7~M4
④
M7~M4
→
M3~M0
⑤
M3~M0
→
overflow
