210
Note: After the SFD register is modified, it is necessary to restart the high-speed counter
(i.e. disconnect and reboot the drive condition) in order to make the new configuration
effective!
5-7 HSC instruction
This section introduces the usage of single-phase high-speed counting instruction (CNT), AB-
phase high-speed counting instruction (CNT_AB), reset of high-speed counting, reading and
writing of high-speed counting.
5-7-1 Single phase HSC [CNT]
1)Instruction Summary
Single phase HSC instruction
XD, XL(exclude
XD1 / XL1 )
2)Operands
Specify HSC code (Eg. HSC0)
Specify comparison value (Eg. K100, D0)
