113
< Written of single word >
<Written of double words>
<Written of four words>
<Written of multi-word>
Write value from D0, D1, D2 to FD0, FD1,FD2
NOTE:
※1: FWRT instruction only can write data into FlashROM register. FlashROM can keep the
data even the power supply is off. It can store the important technical parameters.
※2: Written of FWRT needs a long time, about 500ms, so frequently write-in is not
recommended
※3: The written time of FlashROM is about 1,000,000 times. So we suggest using edge
signal (LDP, LDF etc.) to activate the instruction.
※4: Frequently write-in will damage the FlashROM.
4-5-9 Zone set [MSET]
1)Summary
Set the soft element in certain range
Normally ON/OFF; falling or
rising pulse edge signal
Write value from D0 to FD0
Write value from D0,D1 to FD0,FD1
Write value from D0,D1,D2,D3to FD0,FD1,FD2,FD3.
