Xinje XDH Series - 4-8-11 Hex converts to ASCII [ASCI]

155
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
BCD D10 D0
S· D·
X0
 This instruction can change the binary value to BCD code.
 For example, the PLC clock information registers SD13 to SD19 store BCD code, which
we're used to using decimal values, so you can use the BCD instruction to correct the clock
information in the registers SD13 to SD19.
4-8-11 Hex converts to ASCII [ASCI]
1) Summary
Hex. convert to ASCII [ASCI]
16 bits
ASCI
32 bits
-
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
Description
source (BIN)→destination (BCD)
