Xinje XDH Series User Manual

116
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Consta
nt
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S
●
●
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD;
DM includes DM, DHM; DS includes DS, DHS. M includes M,HM,SM;S includes S,HS;T
includes T,HT;C includes C, HC.
 Exchange the high 8-bit and low 8-bit of 16-bit register.
 If this instruction is activated by normal ON/OFF coil, the instruction will be executed in
every scanning period when X0 is ON. Falling or rising pulse is recommended to activate the
instruction.
4-5-12 Exchange [XCH, DXCH]
1) Summary
Exchange the data in two soft element
Exchange [XCH, DXCH]
16 bits
XCH
32 bits
DXCH
Execution
condition
Rising or falling pulse
edge
Suitable
Models
XD, XL
Hardware
requirement
-
Software
requirement
-
2) Operands
Operands
Function
Data Type
D1
The soft element address
16 bits/32 bits, BIN
D2
The soft element address
16 bits/32 bits, BIN
Description
