195
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
When the M0 switches on, it converts clock data (hours, minutes and seconds) in three
consecutive registers led by HD0 into second data, which is stored in register HD10 (double
word).
Note: the correspondence of registers is fixed, that is, they are stored in order of hours,
minutes and seconds.
The operands S occupy three registers. Do not use them for other purposes.
4-10-8 Convert second data to hours, minutes, and seconds[STOH]
1) Summary
Convert hour, minute, and second data to seconds [STOH]
16 bits
-
32 bits
STOH
Execution
condition
Normally ON/OFF,
rising/falling edge
Suitable
Models
XD, XL
Hardware
requirement
Version V3.4.6 (or V3.5.3a)
or later
Software
requirement
Version V3.5.3 or later
2) Operands
Operands
Function
Data Type
S
Clock data before conversion
16 bits, BIN
D
Clock data after conversion
16 bits, BIN
3) Suitable soft components
Operands
Word soft elements
Bit soft elements
System
Constant
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
Q
D
X
Y
M
S
T
C
Dn.
m
S
D
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
(HDHD1HD2)(HD10,HD11)
Hour, minute ,second second
Description
Description
