Xinje XDH Series User Manual

161
Ignore the 1 of M11
3) Suitable soft components
Operan
ds
Word soft elements
Bit soft elements
System
Constant
Module
System
D
F
D
T
D
C
D
D
X
D
Y
D
M
D
S
K/H
I
D
QD
X
Y
M
S
T
C
Dn.m
S
●
●
●
●
●
●
●
●
●
●
●
●
●
●
D
●
●
●
●
●
●
n
●
*Notes: D includes D, HD; TD includes TD, HTD; CD includes CD, HCD, HSCD, HSD; DM
includes DM, DHM; DS includes DS, DHS. M includes M, HM, SM; S includes S, HS; T
includes T, HT; C includes C, HC.
< When is bit device > n≤16
M10ENCO D10 K3
X0
n
S· D·

If the number of bits in the source address is 1, the low side is ignored, and if the source
address is 0, the instruction will not be executed.

When the driving condition is OFF, the instruction is not executed and the coding output is
unchanged.

When n = 16, if the encoding instruction is a bit element, its point number is 2 ^ 16 = 65536.

N = 3, the encoded object has 2
3
= 8 bits, which are M17 ~ M10, and the encoding results are
stored in the lower three bits of D10, which are bit2 ~ bit0.

M13 and M11 are both 1. Ignoring M11, M13 is coded, bit2-bit0 represent 3, while bit0 and
bit1 are 1.
< When is word device n≤4
D0ENCO D1 K3
X1
n
S· D·
Description
S·
S·
