Xinje XDH Series User Manual

20
Y
Output
points
※5
Y30000~Y30077(#1 expansionED)
64
M
Internal relay
M0~M7999
8000
HM
HM0~HM959
※1
960
SM
Special purposeSM0~SM2047
※2
2048
S
Flow
S0~S1023
1024
HS
HS0~HS127
※1
128
T
Timer
T0~T575
576
HT
HT0~HT95
※1
96
ET
Precise timer ET0~ET31
32
C
Counter
C0~C575
576
HC
HC0~HC95
※1
96
HSC
High speed counter HSC0~HSC31
32
D
Data register
D0~D7999
8000
HD
HD0~HD999
※1
1000
SD
Special purposeSD0~SD2047
2048
HSD
Special purposeHSD0~HSD499
※2
500
FD
FlashROM
register
FD0~FD5119
5120
SFD
Special purposeSFD0~SFD1999
※2
2000
FS
Special secret
register
FS0~FS47
48
ID
※6
Main body
ID0~ID99
100
expansion BD
ID20000~ID20099(#1 expansionBD)
ID20100~ID20199(#2 expansionBD)
200
expansion ED
ID30000~ID30099(#1 expansionED)
100
QD
※7
Main body
QD0~QD99
100
expansion BD
QD20000~QD20099(#1 expansionBD)
QD20100~QD20199(#2 expansionBD)
200
expansion ED
QD30000~QD30099(#1 expansionED)
100
SEM
Special coil of
Sequence
block
instruction
WAIT
SEM0~SEM31
32
XD3 series PLC soft components list:
Name
Range
Points
16 I/O
24 I/O
32 I/O
48 I/O
60 I/O
16
24
32
48
60
X
Input points
X0~X7
X0~X15
X0~X21
X0~X33
X0~X43
8
14
18
28
36
Y
Output points
Y0~Y7
Y0~Y11
Y0~Y15
Y0~Y23
Y0~Y27
8
10
14
20
24
X
Input points
※3
X10000~X10077(#1 expansion module)
……
X11100~X11177(#10 expansion module)
640
Y
Output points
※3
Y10000~Y10077(#1 expansion module)
……
Y11100~Y11177(#10 expansion module)
640
X
Input points
※4
X20000~X20077(#1expansionBD)
X20100~X20177(#2expansionBD)
128
Y
Output points
※4
Y20000~Y20077(#1expansionBD)
Y20100~Y20177(#2expansionBD)
128
