XD5 series PLC soft components list:
Name
Range
Points
16I/O
24 I/O
32 I/O
48 I/O
60 I/O
16
24
32
48
60
X
Input points
X0~X7
X0~X15
X0~X21
X0~X33
X0~X43
8
14
18
28
36
Y
Output points
Y0~Y7
Y0~Y11
Y0~Y15
Y0~Y23
Y0~Y27
8
10
14
20
24
X
Input points
※3
X10000~X10077(#1 expansion module)
……
X11700~X11777(#16 expansion module)
1024
Y
Output
points
※3
Y10000~Y10077(#1 expansion module)
……
Y11700~Y11777(#16 expansion module)
1024
X
Input points
※4
X20000~X20077(#1expansionBD)
X20100~X20177(#2expansionBD)
128
Y
Output
points
※4
Y20000~Y20077(#1expansionBD)
Y20100~Y20177(#2expansionBD)
128
X
Input points
※5
X30000~X30077(#1expansionED)
64
Y
Output
points
※5
Y30000~Y30077(#1expansionED)
64
M
Internal relay
M0~M69999
70000
HM
HM0~HM11999
※1
12000
SM
special purpose SM0~SM4999
※2
5000
S
Flow
S0~S7999
8000
HS
HS0~HS999
※1
1000
T
Timer
T0~T4999
5000
HT
HT0~HT1999
※1
2000
ET
precise timer ET0~ET39
40
C
Counter
C0~C4999
5000
HC
HC0~HC1999
※1
2000
HSC
high speed counter HSC0~HSC39
40
D
Data register
D0~D69999(firmware V3.5.3 and up)
70000
D0~D59999(firmware V3.5.2 and down)
60000
HD
HD0~HD24999
※1
25000
SD
special purpose SD0~SD4999
5000
HSD
special purpose HSD0~HSD1023
※2
1024
FD
FlashROM
Register
FD0~FD8191
8192
SFD
special purpose SFD0~SFD5999
※2
6000
FS
Special secret
register
FS0~FS47
48
ID
※6
Main body
ID0~ID99
100
Expansion
module
ID10000~ID10099(#1 expansion module)
……
ID11500~ID11599(#16 expansion module)
1600
expansion BD
ID20000~ID20099(#1expansionBD)
ID20100~ID20199(#2expansionBD)
200
expansion ED
ID30000~ID30099(#1expansionED)
100
QD
※7
Main body
QD0~QD99
100
Expansion
module
QD10000~QD10099(#1 expansion module)
……
QD11500~QD11599(#16 expansion
module)
1600
