Xinje XDH Series User Manual

28
Expansion
module
ID10000~ID10099(#1 expansion module)
……
ID11500~ID11599(#16 expansion module)
1600
expansion
BD
ID20000~ID20099(#1expansionBD)
ID20100~ID20199(#2expansionBD)
200
expansion
ED
ID30000~ID30099(#1expansionED)
100
QD
※7
Main body
QD0~QD99
100
Expansion
module
QD10000~QD10099(#1 expansion module)
……
QD11500~QD11599(#16 expansion
module)
1600
expansion
BD
QD20000~QD20099(#1expansionBD)
QD20100~QD20199(#2expansionBD)
200
expansion
ED
QD30000~QD30099(#1expansionED)
100
SEM
Special coil
of Sequence
block
instruction
WAIT
SEM0~SEM31
32
XDH series PLC soft components list:
Name
Range
Points
30 I/O
60 I/O
30
60
X
Input points
X0~X17
X0~X43
16
36
Y
Output points
Y0~Y15
Y0~Y27
14
24
X
Input points
※3
X10000~X10077(#1 expansion module)
……
X11700~X11777(#16 expansion module)
1024
Y
Output points
※3
Y10000~Y10077(#1 expansion module)
……
Y11700~Y11777(#16 expansion module)
1024
X
Input points
※4
X20000~X20077(#1 expansion BD)
X20100~X20177(#2 expansion BD)
128
Y
Output points
※4
Y20000~Y20077(#1 expansion BD)
Y20100~Y20177(#2 expansion BD)
128
X
Input points
※5
X30000~X30077(#1 expansion ED)
64
Y
Output points
※5
Y30000~Y30077(#1 expansion ED)
64
M
Internal relay
M0~M19999
200000
HM
HM0~HM19999
※1
20000
SM
special purpose SM0~SM49999
※2
50000
S
Flow
S0~S19999
20000
HS
HS0~HS1999
※1
2000
T
Timer
T0~T19999
20000
HT
HT0~HT1999
※1
2000
ET
Precise timer ET0~ET39
40
C
Counter
C0~C19999
20000
HC
HC0~HC1999
※1
2000
HSC
High speed counter HSC0~HSC39
40
