Xinje XDH Series User Manual

30
S
Flow
S0~S1023
1024
HS
HS0~HS127
※1
128
T
Timer
T0~T575
576
HT
HT0~HT95
※1
96
ET
precise timer ET0~ET31
32
C
Counter
C0~C575
576
HC
HC0~HC95
※1
96
HSC
high speed counter HSC0~HSC31
32
D
Data register
D0~D7999
8000
HD
HD0~HD999
※1
1000
SD
special purpose SD0~SD2047
2048
HSD
special purpose HSD0~HSD499
※2
500
FD
FlashROM
register
FD0~FD5119
5120
SFD
special purpose SFD0~SFD1999
※2
2000
FS
Special secret
register
FS0~FS47
48
ID
※6
Main body
ID0~ID99
100
Expansion module
ID10000~ID10099(#1 expansion
module)
……
ID10900~ID10999(#10 expansion
module)
1000
expansion BD
ID20000~ID20099(#1expansionBD)
ID20100~ID20199(#2expansionBD)
200
expansion ED
ID30000~ID30099(#1expansionED)
100
QD
※7
Main body
QD0~QD99
100
Expansion module
QD10000~QD10099(#1 expansion
module)
……
QD10900~QD10999(#10 expansion
module)
1000
expansion BD
QD20000~QD20099(#1expansionBD)
QD20100~QD20199(#2expansionBD)
200
expansion ED
QD30000~QD30099(#1expansionED)
100
SEM
Special coil of
Sequence block
instruction WAIT
SEM0~SEM31
32
XL3 series PLC soft components list:
Name
Range
Points
16 I/O
32 I/O
16
32
X
Input points
X0~X7
X0~X17
8
16
Y
Output points
Y0~Y7
Y0~Y17
8
16
X
Input points
※3
X10000~X10077(#1 expansion
module)
……
X11100~X11177(#10 expansion
module)
640
