Xinje XDH Series User Manual

33
expansion BD
ID20000~ID20099(#1expansion BD)
ID20100~ID20199(#2expansion BD)
200
expansion ED
ID30000~ID30099(#1expansion ED)
100
QD
※
7
Main body
QD0~QD99
100
Expansion module
QD10000~QD10099(#1 expansion module)
……
QD11500~QD11599(#16 expansion module)
1600
expansion BD
QD20000~QD20099(#1expansion BD)
QD20100~QD20199(#2expansion BD)
200
expansion ED
QD30000~QD30099(#1expansion ED)
100
SEM
Special coil of
Sequence block
instruction WAIT
SEM0~SEM31
32
XLH series PLC soft components list:
Name
Range
Points
24 I/O
24
X
Input points
※5
X0-X13
12
Y
Output points
※5
Y0-Y13
12
X
Internal input
points
X0-X77
64
Y
Internal output
points
Y0-Y77
64
X
Module input
points
※3
X10000~X10077(#1 expansion
module)
……
X11100~X11177(#16
expansion module)
1024
Y
Module output
points
※3
Y10000~Y10077(#1 expansion
module)
……
Y11100~Y11177(#16
expansion module)
1024
X
BD input
points
※4
X20000~X20077(#1 expansion
BD)
X20100~X20177(#2 expansion
BD)
128
Y
BD output
points
※4
Y20000~Y20077(#1 expansion
BD)
Y20100~Y20177(#2 expansion
BD)
128
X
ED input
points
※5
X30000~X30077(#1 expansion
ED)
64
Y
ED output
points
※5
Y30000~Y30077(#1 expansion
ED)
64
M
Internal relay
M0~M199999
200000
HM
HM0~HM19999
※1
20000
SM
special purpose
SM0~SM49999
※2
50000
S
Flow
S0~S19999
20000
