Xinje XDH Series User Manual

370
(4)The SKIP condition only can use M, X, can not use other coil or register.
NO(×)
YES(√)
(5)The output instructions cannot be CNT_AB(CNT), PWM.
NO(×)
YES(√)
(6)BLOCK is not recommended to put in the STL, because if one STL ends, while the
BLOCK doesn’t end, then big problem will happen.
NO(×)
YES(√)
SM0
SBLOCK
FROM K0 K1 K5 D100
WAIT K1 K50
STL S0
SBLOCKE
M100
( )
STLE
Y0
PLSR HD0 HD100 K1 Y0
S0
SBLOCK
FROM K0 K1 K5 D100
WAIT K1 K50
STL S0
SBLOCKE
M100
( )
STLE
Y0
PLSR HD0 HD100 K1 Y0
(7)Label Kind type cannot be used in the block
Sign P, I cannot be used in block. Even they can be added in block, but they do not work in
fact.
