8.5 Options
Table 8.5 and Table 8.6 give detailed information about the available options that allow Yaskawa drives to connect to
communication networks. A host controller can control and monitor the drive, read and change parameters by using a
communication option. Contact Yaskawa or your Yaskawa agent to order options.
• Option Selection: Refer to Yaskawa catalog for more details on option card selection and part numbers.
• Option Installation: Refer to option unit manual for option unit installation instructions.
u
Interface Options
Table 8.5 Interface Option Units
Option Model Function
RS-232C Interface SI-232/J
Allows the user to connect an extension cable for remote operation and for use with
Drive Wizard Plus.
RS-232C Interface (Removable) SI-232/JC
Allows the user to take advantage of the USB Copy Unit option and the Remote
LED Operator option.
RS-422/RS-485 Interface for
MEMOBUS/Modbus Communication
SI-485/J
Allows the drive to connect to a network using MEMOBUS/Modbus RTU protocol.
Option includes a communication cable connector.
Potentiometer AI-V3/J Allows for easier speed control.
u
Other Options
Table 8.6 Other Options
Option Model Function
Remote LED Operator JVOP-182
Allows for remote operation when using the optional LED operator. This option is
used in combination with the LED extension cable and the RS-232C interface.
Option includes a Copy function for saving drive settings.
USB Copy Unit JVOP-181
Saves and transfers parameter settings and connects to a PC for operation with Drive
Wizard Plus. This option is used in combination with the RS-232C interface.
8.5 Options
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
177
8
Peripheral Devices &
Options
