YASKAWA J1000 Technical Manual

C.6 Drive Operations by MEMOBUS/Modbus
The
drive operations that can be performed by MEMOBUS/Modbus communication depend on drive parameter settings. This
section explains the functions that can be used and related parameter settings.
u
Observing the Drive Operation
A PLC can perform the following actions with MEMOBUS/Modbus communications at any time regardless of parameter
settings (except H5-oo).
•
Observe drive status and drive control terminal status from a PLC.
• Read and write parameters.
• Set and reset faults.
•
Set multi-function inputs. Inputs settings from the input terminals So and from MEMOBUS/Modbus communications are
both linked by an OR operation.
u
Controlling the Drive
To start and stop the drive or set the frequency reference using MEMOBUS/Modbus communications, an external reference
must be selected and the parameters listed below must be adjusted accordingly.
Table C.1
Setting Parameters for Drive Control from MEMOBUS/Modbus
Parameter Name Required Setting
b1-01 Frequency Reference Selection 2
b1-02 Run Command Selection 2
Refer to b1-01: Frequency Reference Selection on page 79 and Refer to b1-02: Run Command Selection on page 80 for
details on external reference parameter selections.
C.6 Drive Operations by MEMOBUS/Modbus
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
217
C
MEMOBUS/Modbus Communications
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
