B.2 Parameter Table
An “O” in the “Mode” column indicates that the parameter is available in the Advanced menu.
An “S” in the “Mode” column indicates that the parameter is available in the Startup menu.
u
A: Initialization Parameters
The A parameter group creates the operating environment for the drive. This includes the parameter Access Level, and
Password.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
A1: Initialization Parameters
Use A1 parameters to configure the basic environment for drive operation.
A1-01
<1>
Access Level
Selection
Selects which parameters are accessible via the digital operator.
0: Operation only
2: Advanced Access Level
0, 2 2 O 101 76
A1-03
Initialize
Parameters
Resets all parameters to factory default settings. (Initializes the drive
then returns A1-03 to 0)
0: No Initialize
2220: 2-Wire Initialization
3330: 3-Wire Initialization
0 to 3330 0 O 103 76
E1-03, L8-35, o2-04, o2-09, and all U2 monitors
are not reset when performing initialization.
A1-04 Password 1
When the value set into A1-04 does not match the value set into
A1-05, parameters A1-01 and A1-03 cannot be changed.
0 to 9999 0 O 104 76
A1-05 Password 2
0 to 9999 0 O 105 76
This parameter is hidden from view. To access
A1-05, first display A1-04. Then press the STOP
key while holding down the up arrow key.
Parameter A1-05 will appear.
<1> Parameter can be changed during run.
u
b: Application
Application parameters configure the Run Command Source, DC Injection Braking, and other application-related settings.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
b1: Operation Mode Selection
Use b1 parameters to configure the operation mode.
b1-01
Frequency
Reference
Selection
Selects the frequency reference input source.
0: Operator - Digital preset speed d1-01 to d1-08
1: Terminals - Analog input terminal A1
2: MEMOBUS/Modbus communications (option)
3: Potentiometer (option)
0 to 3 1 S 180 79
b1-02
Run Command
Selection
Selects the run command input source.
0: Operator - RUN and STOP keys on the digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications (option)
0 to 2 1 S 181 80
b1-03
Stopping Method
Selection
Selects the stopping method when the run command is removed.
0: Ramp to Stop
1: Coast to Stop
0, 1 0 S 182 81
b1-04
Reverse Operation
Selection
Permits or prohibits reverse operation.
0: Reverse enabled.
1: Reverse disabled.
0, 1 0 O 183 82
b1-07
LOCAL/REMOTE
Run Selection
Determines the operation when the Run command source is switched
from
LOCAL to REMOTE or between REMOTE and MEMOBUS/
Modbus communication.
0: External Run command has to be cycled at the new source to be
activated.
1: External Run command at new source is accepted immediately.
0, 1 0 O 186 82
b1-08
Run Command
Selection while in
Programming
Mode
0: Run command accepted only in the operation menu.
1: Run command accepted in all menus.
2: Prohibit entering Programming Mode during Run
0 to 2 0 O 187 82
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
189
