YASKAWA J1000 Technical Manual

B.3 Defaults by Drive Model and Duty Rating ND/HD
Table B.2
Single-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Settings
No. Description Unit Default Settings
−
Model CIMR-Jo
− BA0001 BA0002 BA0003
o2-04 Drive Model Selection Hex 30 31 32
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND
0 1 0 1 0 1
− Motor rated power kW 0.1 0.18 0.25 0.37 0.55 0.75
C6-02 Carrier frequency − 4 7 4 7 4 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80
E2-05 Motor line-to-line resistance Ω 35.98 20.56 20.56 9.84 9.842 5.156
−
Momentary power loss ride-through
time
s 0.1 0.1 0.1 0.1 0.1 0.1
− Mom. power loss Baseblock time s 0.2 0.2 0.2 0.2 0.2 0.3
No. Description Unit Default Settings
−
Model CIMR-Jo
− BA0006 BA0010
o2-04 Drive Model Selection Hex 33 34
C6-01 Normal/Heavy Duty −
HD ND HD ND
0 1 0 1
C6-02 Carrier frequency − 4 7 3 7
E2-01 Motor rated current A 3.30 6.20 6.20 8.50
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90
E2-03 Motor no-load current A 1.80 2.80 2.80 3.00
E2-05 Motor line-to-line resistance Ω 5.156 1.997 1.997 1.601
− Momentary power loss ride-through time s 0.2 0.2 0.3 0.3
− Momentary power loss Baseblock time s 0.3 0.4 0.4 0.5
Table B.3 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0001 2A0002 2A0004 2A0006 2A0010
o2-04 Drive Model Selection Hex 60 61 62 63 65
C6-01 Normal/Heavy Duty
− HD ND HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1 0 1
− Motor rated power kW 0.1 0.18 0.25 0.37 0.55 0.75 1.1 1.1 1.5 2.2
C6-02 Carrier frequency − 4 7 4 7 4 7 4 7 3 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30 3.30 4.90 6.20 8.50
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50 2.50 2.60 2.60 2.90
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80 1.80 2.30 2.80 3.00
E2-05 Motor line-to-line resistance Ω
35.98 20.56 20.56 9.84 9.842 5.156 5.156 3.577 1.997 1.601
−
Momentary power loss ride-through
time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
−
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
B.3 Defaults by Drive Model and Duty Rating ND/HD
204
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
