A.4 Drive Specifications
Note: For optimum performance life of the drive, install the drive in an environment that meets the environmental conditions.
Item Specification
Control Characteristics
Control Method V/f Control
Frequency Control Range 0.01 to 400 Hz
Frequency Accuracy
Digital input: within ±0.01% of the max output frequency (-10 to +50 °C)
Analog input: within ±0.5% of the max output frequency (25 °C ±10 °C)
Frequency Setting
Resolution
Digital inputs: 0.01 Hz
Analog inputs: 1/1000 of maximum output frequency
Output Frequency
Calculation Resolution
1/2
20
x Maximum output frequency (E1–04)
Frequency Setting Signal Main frequency reference: 0 to +10 Vdc (20 kΩ), 4 to 20 mA (250 Ω), 0 to 20 mA (250 Ω)
Starting Torque 150%/3 Hz
Speed Control Range 1: 20~40
Accel/Decel Time 0.00 to 6000.0 s (allows four separate settings for accel and decel)
Braking Torque
Instantaneous Average Decel Torque
<1>
: 0.1/0.2 kW: over 150%, 0.4/0.75 kW: over 100%,
1.5 kW: over 50%, 2.2 kW and above: over 20%
Continuous Regen Torque: 20%,
125% with a Braking Resistor Unit
<2>
: (10% ED) 10 s with an internal braking resistor.
V/f Characteristics User-set, programmable.
Functions
• Momentary Power Loss Ride-Thru
•
Speed Search
• Multi-Step Speed (9 steps max)
• Accel/Decel Time Switch
• S-Curve Accel/Decel
• 2-Wire/3-Wire Sequence
• Cooling Fan ON/OFF
• Slip Compensation
• Torque Compensation
• Jump Frequencies (reference dead band)
• Frequency Reference Upper/Lower Limit
• DC Injection Braking (start and stop)
• Overexcitation Braking
• Fault Reset
Protection Functions
Motor Protection Motor overheat protection via output current sensor
Overcurrent Protection Drives stops when output exceeds 200% of the rated current (Heavy Duty)
Overload Protection
A stop command will be entered after operating at 150% for 60 s (Heavy Duty)
<3>
Overvoltage Specification
200 V class: Stops when DC bus voltage exceeds approximately 410 V
400 V class: Stops when DC bus voltage exceeds approximately 820 V
Low Voltage Protection
Drive stops when DC bus voltage falls below the levels indicated:
190
V (3-phase 200 V), 160 V (single-phase 200 V), 380 V (3-phase 400 V), 350 V (3-phase
380 V)
Momentary Power Loss
Ride-Thru
Stops after 15 ms
Heatsink Overheat
Protection
Protected by thermistor
Braking Resistor Overheat
Protection
Overheat input signal for braking resistor (Optional ERF-type, 3% ED)
Stall Prevention
During acceleration and during run: Separate settings for each type of stall prevention
determine the current level at which stall prevention is triggered.
During deceleration: Select, enable/disable.
Cooling Fan Failure
Protection
Circuit protection (“fan-lock” sensor)
Ground Fault Protection
Electronic circuit protection
<4>
DC Bus Charge LED Remains lit until DC bus voltage falls below 50 V
A.4 Drive Specifications
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
183
A
Specifications
