YASKAWA J1000 Technical Manual

A.5 Drive Watt Loss Data
Table A.4
Watt Loss 200 V Class Single-Phase Models
Model Number
CIMR-Jo
Heavy Duty (Carrier Frequency 8/10 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
BA0001 0.8 4.3 7.4 11.7 1.2 5.0 8.5 13.5
BA0002 1.6 7.9 8.9 16.7 1.9 7.6 9.7 17.3
BA0003 3.0 16.1 11.5 27.7 3.3 14.6 14.4 29.1
BA0006 5.0 33.7 16.8 50.5 6.0 30.1 19.4 49.5
BA0010 8.0 54.8 25.9 80.7 9.6 51.7 29.8 81.4
<1> 10 kHz for BA0001 to BA0006
Table A.5
Watt Loss 200 V Class Three-Phase Models
Model Number
CIMR-Jo
Heavy Duty (Carrier Frequency 8/10 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
2A0001 0.8 4.3 7.3 11.6 1.2 5.0 8.0 13.0
2A0002 1.6 7.9 8.8 16.7 1.9 7.6 9.5 17.1
2A0004 3.0 16.2 11.5 27.7 3.5 15.8 13.6 29.4
2A0006 5.0 27.4 15.9 43.3 6.0 27.5 17.2 44.7
2A0010 8.0 54.8 23.8 78.6 9.6 51.7 25.8 77.5
2A0012 11.0 70.7 29.9 100.6 12.0 61.3 30.4 91.7
2A0020 17.5 110.5 43.3 153.8 19.6 98.7 46.3 145.0
<1> 10 kHz for 2A0001 to2A0006
Table A.6
Watt Loss 400 V Class Three-Phase Models
Model Number
CIMR-Jo
Heavy Duty (Carrier Frequency 8 kHz) Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
4A0001 1.2 19.2 11.5 30.7 1.2 10.0 9.6 19.6
4A0002 1.8 28.9 14.8 43.7 2.1 18.5 13.9 32.4
4A0004 3.4 42.3 17.9 60.2 4.1 30.5 16.8 47.3
4A0005 4.8 70.7 26.2 96.9 5.4 44.5 21.8 66.3
4A0007 5.5 81.0 30.7 111.7 6.9 58.5 28.4 86.9
4A0009 7.2 84.6 32.9 117.5 8.8 63.7 31.4 95.1
4A0011 9.2 107.2 41.5 148.7 11.1 81.7 46.0 127.7
A.5 Drive Watt Loss Data
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
185
A
Specifications
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
