YASKAWA J1000 Technical Manual

D.3 UL Standards
The UL/cUL mark applies to products in the United States and Canada indicates that UL has performed product testing and
evaluation and determined that their stringent standards for product safety have been met. For a product to receive UL
certification, all components inside that product must also receive UL certification.
Figure D.7 UL/cUL Mark
u
UL Standards Compliance
This drive is tested in accordance with UL standard UL508C, E131457 and complies with UL requirements. The following
conditions must be met to maintain compliance when using this drive in combination with other equipment:
n
Installation Area
Do not install the drive to an area greater than pollution severity 2 (UL standard).
n
Ambient Temperature
-10 to +40 °C (IP20/NEMA Type 1)
-10 to +50 °C (IP20/Open-Chassis)
n
Main Circuit Terminal Wiring
Yaskawa recommends using UL-listed copper wires (rated at 75 °C) and closed-loop connectors or CSA-certified ring
connectors sized for the selected wire gauge to maintain proper clearances when wiring the drive. Use the correct crimp tool
to install connectors per manufacturer recommendation.
The
wire gauges listed in Table D.3, Table D.4, and Table D.5 are Yaskawa recommendations. Refer to local codes for proper
wire gauge selections.
Table D.3 Wire Gauge and Torque Specifications
Model
CIMR-JoBA
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw Size
Tightening
Torque
N•m (lb.in.)
0001
0002
0003
R/L1, S/L2, T/L3 14 18 to 14
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2, W/T3 14 18 to 14
–, +1, +2 – 18 to 14
B1, B2 – 18 to 14
14 18 to 14
0006
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0010
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
D.3 UL Standards
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
241
D
Standards Compliance
