d: References
Reference parameters are used to set the various frequency reference values during operation.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01
<1>
Frequency
Reference 1
Frequency reference. Refer to b1-01: Frequency Reference
Selection on page 79 for instructions to use d1-01 as the main
frequency reference.
0.00 to
400.00 Hz
<2>
0.00 Hz S 280 90
d1-02
<1>
Frequency
Reference 2
Frequency reference when digital input "Multi-Step Speed Reference
1" (H1-oo = 3) is on.
0.00 Hz S 281 90
d1-03
<1>
Frequency
Reference 3
Frequency reference when digital input "Multi-Step Speed Reference
2” (H1-oo = 4) is on.
0.00 Hz S 282 90
d1-04
<1>
Frequency
Reference 4
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2" (H1-oo = 3 and 4) are on.
0.00 Hz S 283 90
d1-05
<1>
Frequency
Reference 5
Frequency reference when digital input "Multi-Step Speed Reference
3" (H1-oo = 5) is on.
0.00 Hz O 284 90
d1-06
<1>
Frequency
Reference 6
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3 " (H1-oo = 3 and 5) are on.
0.00 Hz O 285 90
d1-07
<1>
Frequency
Reference 7
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3" (H1-oo = 4 and 5) are on.
0.00 Hz O 286 90
d1-08
<1>
Frequency
Reference 8
Frequency reference when multi-function input "Multi-Step speed
reference 1, 2, 3" (H1-oo = 3, 4, 5) are on.
0.00 Hz O 287 90
d1-17
<1>
Jog Frequency
Reference
Frequency reference when digital inputs "Jog Frequency Reference",
"Forward Jog" or "Reverse Jog." are on.
6.00 Hz S 292 90
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency
Reference Upper
Limit
Sets the frequency reference upper limit as a percentage of maximum
output
frequency (E1-04). Output speed is limited to this value even
if the frequency reference is higher. This limit applies to all frequency
reference sources.
0.0 to 110.0
100.0
%
O 289 91
d2-02
Frequency
Reference Lower
Limit
Sets the frequency reference lower limit as a percentage of maximum
output frequency (E1-04). Output speed is limited to this value even
if the frequency reference is lower. This limit applies to all frequency
reference sources.
0.0 to 110.0 0.0% O 28A 91
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
d3-01 Jump Frequency 1 d3-01 to d3-04 allow programming of three prohibited frequency
reference points for eliminating problems with resonant vibration of
the motor/machine. This feature does not eliminate the selected
frequency values, but accelerates and decelerates the motor through
the prohibited bandwidth.
The parameters must be according to the rule
d3-01 ≥ d3-02 .
0.0 to 400.0
0.0 Hz O 294 92
d3-02 Jump Frequency 2 0.0 Hz O 295 92
d3-04
Jump Frequency
Width
This parameter sets the dead-band width around each selected
prohibited frequency reference point. The bandwidth becomes the
designated Jump frequency, plus or minus d3-04.
0.0 to 20.0 1.0 Hz O 297 92
d4: Frequency Reference Hold
Use d4 parameters to configure the drive frequency reference hold function.
d4-01
Frequency
Reference Hold
Function Selection
Determines if the frequency reference or frequency reference bias is
saved when the Run command is removed or the power goes off.
0: Disabled
1: Enabled
This parameter is effective when the multi-function inputs “Accel/
Decel Ramp Hold” or “Up/Down” commands are selected (H1-
oo = A or 10/11).
0, 1 0 O 298 93
<1> Parameter can be changed during run.
<2>
Range upper limit is dependent on parameters E1-04, Maximum Output Frequency, and d2-01, Frequency Reference Upper Limit.
B.2 Parameter Table
192
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
