H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H1: Multi-Function Digital Input
H1 parameters to assign functions to the multi-function digital input terminals. Unused terminals should be set to "F".
H1-01
Multi-Function Digital Input
Terminal S1 Function
Selection
Assigns a function to the multi-function digital inputs.
Refer
to H1 Multi-Function Digital Input Selections on
page 194 for a description of setting values.
1 to 67
40 O 438 98
H1-02
Multi-Function Digital Input
Terminal S2 Function
Selection
41 O 439 98
H1-03
Multi-Function Digital Input
Terminal S3 Function
Selection
0 to 67
24 O 400 98
H1-04
Multi-Function Digital Input
Terminal S4 Function
Selection
14 O 401 98
H1-05
Multi-Function Digital Input
Terminal S5 Function
Selection
3 (0)
<1>
O 402 98
<1> Parenthetical value is the default when parameter A1-03 = 3330 3-Wire Initialization.
H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description Page
0 3-Wire Sequence Closed: Reverse rotation (only if the drive is set up for 3-Wire sequence) 98
1 LOCAL/REMOTE Selection
Open: REMOTE, Run and frequency reference source set in b1-01/02
Closed: LOCAL, LED operator is run and reference source
99
2
Serial Communication Reference
Selection
Open: REMOTE, Run and frequency reference source set in b1-01/02
Closed: MEMOBUS/Modbus Communication
99
3 Multi-Step Speed Reference 1
Used to select Multi-Step Speeds set in d1-01 to d1-08
99
4 Multi-Step Speed Reference 2 99
5 Multi-Step Speed Reference 3 99
6 Jog Reference Selection
Open: Selected speed reference
Closed: Jog Frequency reference (d1-17). Jog has priority over all other reference
sources.
99
7 Accel/Decel Time 1 Used to switch between Accel/Decel Time 1 and 2 99
8 Baseblock Command (N.O.)
Open: Normal operation
Closed: No drive output
100
9 Baseblock Command (N.C.)
Open: No drive output
Closed: Normal operation
100
A Accel/Decel Ramp Hold
Closed: The drive pauses during acceleration or deceleration and maintains the
output frequency.
100
F Not used
Select this setting when not using the terminal or when using the terminal in a
pass-through mode.
100
10 Up Command Open: Maintains the current frequency reference
Closed: Increases or decreases the current frequency reference.
Ensure that the increase and decrease commands are set in conjunction with one
another.
100
11 Down Command 100
14 Fault Reset Closed: Resets faults if the cause is cleared and the Run command is removed. 101
15 Fast-Stop (N.O.)
Closed: Decelerates at the Fast-Stop time C1-09.
To restart the Fast-Stop input must be released and Run must be cycled.
102
17 Fast-stop (N.C.) Open: Decelerates according to C1-09 (Fast-stop Time) 102
B.2 Parameter Table
194
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
