6.3 Drive Alarms, Faults, and Errors
u
Types of Alarms, Faults, and Errors
Check the LED operator for information about possible faults if the drive or motor fails to operate. Refer to Using the Digital
LED Operator on page 58.
If problems occur that are not covered in this manual, contact the nearest Yaskawa representative with the following
information:
• Drive model
• Software version
• Date of purchase
• Description of the problem
Table 6.3 contains descriptions of the various types of alarms, faults, and errors that may occur while operating the drive.
Contact Yaskawa in the event of drive failure.
Table 6.3 Types of Alarms, Faults, and Errors
Type Drive Responses to Alarms, Faults, and Errors
Faults
When the drive detects a fault:
•
The digital operator displays text that indicates the specific fault and the ALM indicator LED remains lit until the fault is
reset.
• The fault interrupts drive output and the motor coasts to a stop.
• Depending on the setting, the drive and motor may stop via different methods than listed.
• If a digital output is programmed for fault output (H2-01 = E), it will close if a fault occurs.
When the drive detects a fault, it will remain inoperable until that fault has been reset. Refer to Fault Reset Methods on page
146.
Minor Faults and
Alarms
When the drive detects an alarm or a minor fault:
•
The digital operator displays text that indicates the specific alarm or minor fault and the ALM indicator LED flashes.
• The motor does not stop.
• The multi-function contact output closes if set to be tripped by a minor fault (H2-01 = 10), but not by an alarm.
• The digital operator displays text indicating a specific alarm and ALM indicator LED flashes.
Remove the cause of an alarm or minor fault to automatically reset.
Operation Errors
When parameter settings conflict with one another or do not match hardware settings (such as with an option unit), it results
in an operation error.
When the drive detects an operation error:
•
The digital operator displays text that indicates the specific error.
• The multi-function contact output does not operate.
When the drive detects an operation error, it will not operate the motor until the error has been reset. Correct the settings that
caused the operation error to reset.
u
Alarm and Error Displays
n
Faults
When
the drive detects a fault, the ALM indicator LEDs remain lit without flashing. If the LEDs flash, the drive has detected
a minor fault or alarm. Refer to Minor Faults and Alarms on page 132 for more information. Conditions such as overvoltage
or external faults can trip both faults and minor faults, therefore it is important to note whether the LEDs remain lit or if the
LEDs flash.
Table 6.4 Fault Displays
LED Operator Display Name Pg.
CE
MEMOBUS/Modbus
Communication Error
133
CoF Current Offset Fault 133
LED Operator Display Name Pg.
or
<1>
CPF00 or
CPF01
CPF11 – RAM Fault 133
CPF12 – FLASH Memory Fault 133
CPF14 – Control Circuit Fault 133
CPF17 – Timing Fault 133
CPF18 – Control Circuit Fault 133
CPF02 A/D Conversion Error 133
6.3 Drive Alarms, Faults, and Errors
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
131
6
Troubleshooting
