YASKAWA J1000 Technical Manual

Model
CIMR-JoBA
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw Size
Tightening
Torque
N•m (lb.in.)
0010
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
n
Three-Phase 200 V Class
Table 3.3 Wire Gauge and Torque Specifications
Model
CIMR-Jo2A
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw Size
Tightening
Torque
N•m (lb.in.)
0001
0002
0004
0006
R/L1, S/L2, T/L3 14 18 to 14
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2, W/T3 14 18 to 14
–, +1, +2 – 18 to 14
B1, B2 – 18 to 14
14 18 to 14
0010
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0012
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
0020
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
n
Three-Phase 400 V Class
Table 3.4
Wire Gauge and Torque Specifications
Model
CIMR-Jo4A
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw Size
Tightening
Torque
N•m (lb.in.)
0001
0002
0004
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
14 14 to 10
0005
0007
0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
–, +1, +2 – 14 to 10
B1, B2 – 14 to 10
10 14 to 10
3.6 Main Circuit Wiring
40
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
