H1 Multi-Function Digital Input Selections
H1-oo
Setting
Function Description Page
20 to 2F External Fault
20: N.O., Always Detected, Ramp To Stop
21: N.C., Always Detected, Ramp To Stop
22: N.O., During Run, Ramp To Stop
23: N.C., During Run, Ramp To Stop
24: N.O., Always Detected, Coast To Stop
25: N.C., Always Detected, Coast To Stop
26: N.O., During Run, Coast To Stop
27: N.C., During Run, Coast To Stop
28: N.O., Always Detected, Fast-stop
29: N.C., Always Detected, Fast-stop
2A: N.O., During Run, Fast-stop
2B: N.C., During Run, Fast-stop
2C: N.O., Always Detected, Alarm Only (continue running)
2D: N.C., Always Detected, Alarm Only (continue running)
2E: N.O., During Run, Alarm Only (continue running)
2F: N.C., During Run, Alarm Only (continue running)
102
40
Forward Run Command (2-Wire
sequence)
Open: Stop
Closed: Forward run
103
41
Reverse Run Command (2-Wire
sequence)
Open: Stop
Closed: Reverse run
103
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the max. output frequency
(E1-04)
103
62 External Search Command 2 Closed: Activates Current Detection Speed Search from the frequency reference 103
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-422/485 interface. 103
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H2: Multi-Function Digital Output MA-MB-MC
Use H2 parameters to assign functions to the multi-function digital output MA-MB-MC.
H2-01
Terminal MA, MB
and MC Function
Selection (relay)
Refer to H2 Multi-Function Digital Output Settings on page 195 for
a description of setting values.
0 to 13D E O 40B 103
H2 Multi-Function Digital Output Settings
H2-01
Setting
Function Description Page
0 During Run Closed: A Run command is active or voltage is output 104
1 Zero Speed Closed: Output frequency is 0 104
2 Speed Agree 1
Closed: Output frequency equals the speed reference (plus or minus 2 Hz
hysteresis)
104
4 Frequency Detection 1
Closed: Output frequency is less than or equal to the value in L4-01 with 2 Hz
hysteresis
105
5 Frequency Detection 2 Closed: Output frequency is greater than the value in L4-01 with 2 Hz hysteresis 105
6 Drive Ready
Closed: Drive Ready. The drive is powered up, not in a fault state, and in the Drive
mode
106
7 DC Bus Undervoltage Closed: DC bus voltage is below the Uv trip level 106
8 During Baseblock (N.O.) Closed: There is no output voltage 106
B Torque Detection 1 (N.O.)
Closed: Output current/torque exceeds the torque value set in parameter L6-02
for longer than the time set in parameter L6-03
106
E Fault Closed: Fault occurred (other than CPF00 and CPF01) 106
F Not used
Set this value when the terminal is not used, or when using the terminal in the
pass-through mode
106
10 Minor Fault Closed: An alarm is triggered 107
17 Torque Detection 1 (N.C.)
Open: When the output current exceeds the value set in parameter L6-02 for more
time than is set in parameter L6-03
106
1A Reverse Direction Closed: Drive is running in the reverse direction 107
1E Restart Enabled Closed: An automatic restart is performed 107
3C LOCAL/REMOTE Status
Closed: LOCAL
Open: REMOTE
107
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
195
B
Parameter List
