YASKAWA J1000 Technical Manual

No. Name Description
Analog Output
Level
Unit Mode
Addr.
Hex
U4-08
Heatsink
Temperature
Displays the heatsink temperature. 10 V: 100 °C 1 °C O 68
U4-09 LED Check
Lights all segments of the LED to verify that the display is
working properly.
No signal output avail. – O 3C
U4-13 Peak Hold Current Displays the peak hold current during run. No signal output avail.
0.01 A
<1>
O 7CF
<1> U1-03 and U4-13 display monitor contents in amp units. When reading the value of these monitors via MEMOBUS/Modbus, a value of 8192 is
equal to 100% of the drive rated output current.
<2>
When this value reaches 100%, the maintenance period has been reached for the component in question and the drive is at risk of faulting out due
to component failure. Periodically check the maintenance monitors to avoid this situation.
B.2 Parameter Table
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
203
B
Parameter List
http://nicontrols.com

YASKAWA J1000 Specifications

General

Series	J1000
Voltage Class	200V, 400V
Frequency	50/60 Hz
Enclosure Rating	IP20
Enclosure Type	Open type
Voltage	200-240V, 380-480V
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault, Short Circuit
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Humidity	5-95% (non-condensing)
Enclosure	IP20
Input Voltage	200-240V, 380-480V
