YASKAWA J1000 Technical Manual

No. Description Unit Default Settings
−
Model CIMR-Jo
− 2A0012 2A0020
o2-04 Drive Model Selection Hex 66 68
C6-01 Normal/Heavy Duty −
HD ND HD ND
0 1 0 1
− Motor rated power kW 2.2 3.0 4.0 5.5
C6-02 Carrier frequency − 3 7 3 7
E2-01 Motor rated current A 8.50 11.40 14.0 19.60
E2-02 Motor rated slip Hz 2.90 2.70 2.73 1.50
E2-03 Motor no-load current A 3.00 3.70 4.50 5.10
E2-05 Motor line-to-line resistance Ω 1.601 1.034 0.771 0.399
− Momentary power loss ride-through time s 0.5 0.5 1 1
− Momentary power loss Baseblock time s 0.5 0.5 0.6 0.7
Table B.4 Three-Phase 400 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
−
Model CIMR-Jo
− 4A0001 4A0002 4A0004 4A0005
o2-04 Drive Model Selection Hex 91 92 93 94
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
− Motor rated power kW 0.37 0.37 0.55 0.75 1.1 1.5 1.5 2.2
C6-02 Carrier frequency − 3 7 3 7 3 7 3 7
E2-01 Motor rated current A 0.60 1.00 1.00 1.60 1.60 3.10 3.10 4.20
E2-02 Motor rated slip Hz 2.50 2.90 2.90 2.60 2.60 2.50 2.50 3.00
E2-03 Motor no-load current A 0.40 0.60 0.60 0.80 0.80 1.40 1.40 1.50
E2-05 Motor line-to-line resistance Ω 83.94 38.20 38.198 22.459 22.459 10.1 10.1 6.495
−
Momentary power loss ride-through
time
s 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
−
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
No. Description Unit Default Setting
−
Model CIMR-Jo
− 4A0007 4A0009 4A0011
o2-04 Drive Model Selection − 95 96 97
C6-01 Normal/Heavy Duty −
HD ND HD ND HD ND
0 1 0 1 0 1
− Motor rated power kW 2.2 3.0 3.0 4.0 4.0 5.5
C6-02 Carrier frequency − 3 7 3 7 3 7
E2-01 Motor rated current A 4.20 5.70 5.70 7.00 7.00 9.80
E2-02 Motor rated slip Hz 3.00 2.70 2.70 2.70 2.70 1.50
E2-03 Motor no-load current A 1.50 1.90 1.90 2.30 2.30 2.60
E2-05 Motor line-to-line resistance Ω 6.495 4.360 4.360 3.333 3.333 1.595
− Momentary power loss ride-through time s 0.5 0.5 0.5 0.5 0.5 0.5
− Momentary power loss Baseblock time s 0.5 0.5 0.5 0.6 0.6 0.7
B.3 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA ELECTRIC SIEP C710606 31B YASKAWA AC Drive – J1000 Technical Manual
205
B
Parameter List
